Description
Summary
DoMain is GEPRC’s new generation of consumer Freestyle FPV drone, It brings pilots the GEPRC team’s comprehensive technical evolution, as well as a deep comprehension of the Freestyle quadcopters , DoMain is made for the dream Freestyle FPV drone what we’ve been looking for.
Feature
- Unique structure design,Increase the stability of the frame structure.
- The new side panel design is integrated, supporting DIY side panel decals.Higher creativity and diversity.
- Equipped with sufficient power, it can complete difficult freestyle flight.
- Support full-size GOPRO or naked GOPRO on itself, Shooting all perfect footages in the view
- DC structure design, the frame looks neat and compact.The extraordinary high integration, Without Prop in the view, showing you a pure picture.
- Equipped with M-10 GPS to ensure the safety of every flight with rescue mode.
Specifications
- Product name: 4.2DoMain
- Frame：GEP-DoMain
- Wheelbase：190mm
- Top plate thickness: 2mm
- Base plate thickness: 2.5mm
- Arm thickness:4.0mm
- Midplate thickness：3mm
- FC：TAKER F722 SE
- ESC：TAKER E55A 32Bit 4IN1
- MCU： STM32F722RET6
- Gyro: MPU6000
- OSD：AT7456E
- VTX：O3 Air Unit
- Camera：O3 camera
- Antenna：5.8G&2.4G
- Motor：SPEEDX2 2105.5 2650KV
- Propellers: GEMFAN 3630 – 3
- Weight: 295g ±5g
- Receiver：PNP/ TBS NanoRX / GEPRC ELRS2.4
- Recommend battery：Lipo 6S 1050-1300mah
Includes
1 x DoMain
2 x GEMFAN 3630-3(1 pair)
2 x M15*200mm Battery cable tie
1 x Spare screw bag
1 x L-shaped screwdriver(1.5mm)
1 x L-shaped screwdriver (2mm)
1 x M8 Wrench
1x Left and right side panels
