Description
The new iFlight blitz series offers stellar performance at an affordable price. With an F7 processor and high-quality BMI270 gyro, this FC is all you could ever need for daily cruising or even hardcore freestyle and racing! And with these new 55 Amp BLHeli 32 Blitz 4-in-1 ESCs, you can handle even the most amp-hungry motors.on!
Specifications
Blitz Mini F722
- Input Voltage: 2-6S
- MCU: STM32F722
- Gyro: BMI270
- Barometer: DPS310
- OSD Chip: AT7456
- Blackbox: 16MB
- UARTS: 6
- Motor outputs: 4x (SH1.0 connector)
- I2C: SDA / SLA pads
- LED: Yes
- Beeper: Yes
- Firmware Target: IFRC-IFLIGHT_BLITZ_F722
- FC Mounting Pattern: 20x20mm
- Dimensions: 30.5x27mm
Blitz Mini E55 4in1 ESC
- Input Voltage: 2-6S
- Max. Continuous Current: 55A
- Max. Burst Current: 60A
- MCU: G071
- BEC: No
- Current Sensor: Yes
- Firmware: BLHeli32
- Target: IFLIGHT_BLITZ_G1
- Mounting Dimensions: 20x20mm/Φ4mm
- Dimensions 35x42mm
- Weight: 11.3g
Includes
- 1x iFlight Blitz F7 Mini V1.1 20x20 Flight Controller
- 1x iFlight Blitz Mini E55 32Bit 55A 2-6S 20x20 4in1 ESC
- 1x Wiring Set
Wiring Diagram
