Description
SPECIFICATIONS:
- Sensor Type: Sony 1/3" CMOS Sensor
- Scale: 4:3(default)/16:9 Switchable
- Tv System: PAL(default)/NTSC Switchable
- Resolution: 1000TVL
- Shutter Speed: PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec
- Video Output: CVBS Analog Signal
- FOV :
- 1.8mm: FOV-H:115° FOV-D: 150°
- 2.5mm: FOV-H:105° FOV-D: 130°
- Shutter Speed: Auto
- Minimum Illumination: 0.01Lux
- White Balance: Auto
- DNR: 3DNR 2DNR
- WDR: Super WDR
- DAY/NIGHT Auto/Color/B&W
- Flight OSD: Voltage/Cam Title/Time/Cross Hair
- Mode: DAY/CLOUDY/Night/LED
- Fast Mode Switch: Long Press Right Button to switch among DAY/CLOUDY/Night/LED
- Input Voltage: 4.5V~20V
- Working Temperature: -10°~50°C RH90% MAX
- Working Humidity: 20~80%
- Storage Temperature: -20°~70°C
- Consumption: 50mA±15% @ DC12V 115mA±15% @ DC5V
- Dimension: 22*22mm; 28*22mm(Add Bracket)
- Weight: 12g(Exclude cable)
